From laboratories to homes, coarse stainless steel wire mesh is used in a variety of industries. Fashionable stainless steel woven mesh fireplace screens protect onlookers from flying sparks. Multipurpose air vents provide ventilation in countless locations. Stainless steel mesh gutter guards keep gutters clear of leaves and other debris.
Product Description
Dimensions
Mateiral: 201, 302, 304, 304L,316,316L, 321,Pure Nickel,Monel. Etc
Mesh size: 1–20 mesh.
Roll width: 0.914 m, 1.0 m, 1.22 m and customized sizes.
Roll length: 30 m, 50 m, 100 m and customized lengths.
Customized specifications on large quantity order are also available.
Mesh/Inch | Wire Diameter | Opening | ||
mm | inch | mm | inch | |
1 | 3 | 0.118 | 22.4 | 0.882 |
2 | 1 | 0.039 | 11.70 | 0.461 |
2 | 1.5 | 0.059 | 11.2 | 0.441 |
2 | 1.6 | 0.063 | 11.10 | 0.437 |
3 | 1.2 | 0.047 | 7.27 | 0.286 |
4 | 1 | 0.039 | 5.35 | 0.211 |
4 | 1.19 | 0.047 | 5.16 | 0.203 |
5 | 1 | 0.039 | 4.08 | 0.161 |
6 | 0.9 | 0.035 | 3.33 | 0.131 |
7 | 0.8 | 0.031 | 2.83 | 0.111 |
8 | 0.7 | 0.028 | 2.48 | 0.097 |
8 | 0.8 | 0.031 | 2.38 | 0.094 |
10 | 0.3 | 0.012 | 2.24 | 0.088 |
10 | 0.6 | 0.024 | 1.94 | 0.076 |
10 | 0.61 | 0.024 | 1.93 | 0.076 |
10 | 0.63 | 0.025 | 1.91 | 0.075 |
